Qotom

Qotom Multi LAN Desktop Router PC Q71200G6 i3 i5

$218.00 USD

~~$0.00 USD~~ $218.00 USD

Sale Sold out

Shipping calculated at checkout.

Q71200G6 Q71211G6 G6900 Q71221G6 G7400 Q71231G6 i3-12100 Q71251G6 i5-12400 Q71331G6 i3-13100 Q71351G6 i5-13400

Configuration Barebone 4G RAM 128G SSD 8G RAM 128G SSD 16G RAM 256G SSD 16G RAM 512G SSD 32G RAM 512G SSD 64G RAM 1T SSD

Quantity

Instructions before purchase

1. Import Duties & VAT & other fees (If Any) should by paid by buyer.

2. Shipping way: DHL, UPS, FedEx

3. Place of dispatch: Shenzhen, China

4. Product contain Qotom Logos by default (on Computer case, Boot up screen, product label).

If you need to add your LOGO or don't need the Qotom logo, pls contact me within 2 hours after placing the order.

5. Preinstall Ubuntu by default (except barebone device).

6. Pre-set up the function of automatic start after power connected.

7. If you require an Invoice (PDF file) or have other questions, pls email to sally@qotom.com

Processor System
CPU	• Intel 12th Alder lake -S Processor • Intel 13th Raptor Lake-S Processor
CPU TDP	By CPU
Memory	2 × DDR4 SO-DIMM Socket (Up to 64G)
Chipset	Intel H610
Graphics	By CPU
LAN Chipset	6 × Intel I225-V/I226-V 2.5 Gigabit LAN
Audio	No
Watch Dog	Yes
Power Button	1
Power Button	1 × Power Button, 1 × Reset Button
LED	1 × Power LED, 1 × HDD LED
Serial Port	0
USB	2 × USB 2.0
Rear I/O
Power	1 × DC Jack
Video Output	1 × Display Port, 1 × HDMI
LAN	6 × Intel I225-V/I226-V 2.5 Gigabit LAN
USB	0
Audio	0
Serial Port	0
Storage
Type	1 × 2.5-inch HDD/SSD 1 × M.2 for SSD (M key, Type: 2280, PCIe 4.0 × 4)
Expansion
M.2	1 × M.2 for SSD (M key, Type: 2280) 1 × M.2 for Wi-Fi (E key, Type: 2230) 1 × M.2 for 4G/5G (B key, Type: 3042/3052)
SIM Card Slot	1
AutoStart Jumper	Yes, 1 × 3Pin, Pitch 2.0mm
CMOS Clear Jumper	Yes, 1 × 3Pin, Pitch 2.0mm
GPIO	1, 2 × 5Pin, Pitch 2.0mm
RS-485	0
Serial Port	0
Power Adapter	19V4.74A (Power cord is included)
DC Jack	5.5mm, 2.5mm
Environmental
Operating Temp	0°C~50°C
Non-Operating Temp	-20°C~80°C
Humidity	10%~90%
Mechanical
Material	Aluminium Alloy
Dimension	S15: 200 × 200 × 53mm
Weight	1.6kg
Mounting	VESA Mounting Bracket
Packaging Dimension	285 × 260 × 120mm
Kensington Lock	Yes
Cooling Mode	Fan
OS Support, Drivers, Bios
OS	UEFI Windows 10, UEFI Linux
Drivers	Visit
Bios	Visit
