Qotom Multi LAN Firewall Router PC Q10900G6 N100 N305 N150 N355

Dear all clients, especially from European and American, to avoid misunderstandings, please read the "Instructions Before Purchase" carefully, we don't accept any return or refund requests due to customs duties. Please be aware of this before purchasing. Thank you for your understanding.

Instructions before purchase

1. Import Duties & VAT & other fees (If Any) should be paid by buyer.

2. Shipping way: DHL, UPS, FedEx

3. Place of dispatch: Shenzhen, China

4. Product contain Qotom Logos by default (on Computer case, Boot up screen, product label).

If you need to add your LOGO or don't need the Qotom logo, pls contact me within 2 hours after placing the order.

5. Preinstall Ubuntu by default (except barebone device).

6. Pre-set up the function of automatic start after power connected.

7. If you require an Invoice (PDF file) or have other questions, pls email to sally@qotom.com

Processor System
CPU	Intel Alder Lake-N Processor Intel Twin Lake-N Processor
CPU TDP	By CPU
Memory	1 × DDR5 SO-DIMM Socket (Up to 48G)
Chipset	By CPU
Graphics	By CPU
LAN Chipset	6 × Intel I226-V 2.5 Gigabit LAN
Watch Dog	Yes
Front I/O
Power Button	1 × Power Button, 1 × Reset Button
LED	1 × Power LED, 1 × HDD LED
SIM Slot	1 × Nano SIM Slot
Serial Port	1 × RS-232 Port (DB9)
Video Output	1 × HDMI, 1 × Display Port
USB	1 × USB 3.0, 1 × USB 2.0
Type C	1 × Type C (USB 3.0, Display Port)
Rear I/O
Power	1 × DC Jack
LAN	6 × Intel I226-V 2.5 Gigabit LAN
Storage
Type	1 × M.2 for SSD (M key, Type: 2280, PCIe 3.0 × 1) 1 × 2.5-inch HDD/SSD
Expansion
eMMC	No
M.2	1 × M.2 for 4G/5G (B key, Type: 3042/3052)
M.2	Wi-Fi support via a Converter Card (Option) 5G Mode Requires Customization
SIM Card Slot	1
AutoStart Jumper	Yes, 1 × 3Pin, Pitch 2.54mm
CMOS Clear Jumper	Yes, 1 × 3Pin, Pitch 2.0mm
Power Header	1, 1 × 2Pin, Pitch 3.5mm, Phoenix 2Pin
Power Requirement
Power Adapter	12V5A(Power cord is included)
DC Jack	5.5mm, 2.5mm
Environmental
Operating Temp	0°C~50°C
Non-Operating Temp	-20°C~80°C
Humidity	10%~90%
Mechanical
Material	Aluminium Alloy
Dimension	S08: 155 × 127 × 48mm
Weight	0.86kg
Mounting	VESA Mounting Bracket
Packaging Dimension	261 × 218 × 75mm
Kensington Lock	No
Cooling Mode	Fanless Design, Fan-Assisted Cooling
OS Support, Drivers, Bios
OS	UEFI Windows, UEFI Linux
Drivers	Visit
Bios	Visit
